Ống cao su thủy lực - 6 lớp bố thép

Model: EFG5K - GATES

Tài liệu kỹ thuật:

Ống cao su thủy lực - 6 lớp bố thép

Mô tả sản phẩm

EFG5K Spiral Wire Hose - SAE 100R13

Extremely High Pressure

For Biodegradable Hydraulic Fluids

Meets Flame Resistance Acceptance Designation "MSHA 2G"

Recommended For: Extremely high-pressure high-impulse applications.

Exceeds all requirements of ISO 18752 Grade D and SAE 100R13 and
performance requirements of EN 856 4SH (-16 and -20), EN 856 4SP (-10,
and -12), EN 856 R13, and ISO 3862 Type R13 (-12, -16, -20, -24, -32).
Compatible with biodegradable hydraulic fluids like polyolester, polyglycol
and vegetable oil as well as standard petroleum-based fluids. Available in
121' through 200' continuous lengths.
Tube: Black, oil resistant, synthetic rubber (Nitrile - Type C). See Hose
Stock Characteristics.
Reinforcement: Four (six for -20, -24 and -32) alternating layers of spiraled,
high-tensile steel.
Cover: Black, oil resistant, synthetic rubber (Polychloroprene - Type A), with
color coded layline. Also available with unique abrasion resistant MegaTuff®
cover. See Hose Stock Characteristics.
Temperature Range: -40°F to +250°F (-40°C to +121°C). For water
emulsions see Temperature Limits Table.
Coupling Recommendation (See gates.com/ecrimp or Crimp Data
Manual 35019)
GlobalSpiral™ Couplings (-6 through -20) (Section E)
GlobalSpiral™ MAX Pressure Couplings (-24 and -32) (Section E)
Stainless Steel "S" Couplings (Section H)
